Automated Optical Inspection (AOI) uses high-resolution cameras and software to capture manufacturing errors. The software essentially compares multiple images of the inspected circuit board with a "golden" board image stored in its memory and marks any differences.
These machines can be placed on the entire SMT production line. Inspection after the reflow soldering stage can identify soldering defects such as dry joints, solder bridges, insufficient wetting, tombstone defects, and more. Operators can then make finer adjustments to preceding stages based on the machine's feedback to minimize defects.
Although AOI technology has made significant progress, it still has some weaknesses. On one hand, AOI is not adept at through-hole components. It can capture many through-hole errors, such as component errors or absence, but height variations, shadow projections, and hidden components may limit AOI's effectiveness. Programming also takes some time, adding extra overhead.
X-ray Inspection X-ray inspection is required for components with hidden leads. Beneath the BGA, there are arranged pins that cannot be visually inspected after soldering. X-ray is used to inspect whether all leads are correctly soldered.
First Article Inspection To validate procedures and components, OEMs often require a first article inspection of the product. The company's fixed asset investment plans differ. Some require the CM to verify the completion of FAI in written documentation, while others request the actual article for approval. It is crucial to communicate with the CM to check all the necessary checkboxes, no matter what you deem necessary.
Online and Functional Testing Online Testing: This testing form requires a custom fixture, commonly known as a bed of nails. Typically, several spring-loaded metal probes are assembled in an array on an insulated bed. If ICT testing is considered a critical form of testing, it is usually planned during the design stage, as it requires the designer to place test pads in critical locations on the PCB's bottom layer copper traces.
The test instrument places the assembled PCB onto the probes to electrically connect it to the test pads. Sometimes it is done manually or built-in within the fixture. The test then checks various parameters, such as resistance, capacitance, and inductance between specified probes, and marks any deviations from established standards.
Functional Testing: This method can vary significantly. It essentially simulates on-site equipment. The test procedure is created by the OEM and handed over to the CM for execution. It typically involves a power supply and multiple inputs to ensure the circuit board functions as expected.
Aging Testing Aging testing simulates real-life conditions. PCB components are subjected to elevated temperatures for 24 hours and held for a specified period. After cooling, the board should not exhibit any expected performance issues. This can be validated through functional testing or ICT.
Our Inspection and Testing We provide inspection and testing methods here based on customer requirements. Whether your PCB requires multiple forms of testing or a few, our experienced team is here to assist you. We provide detailed explanations and share a guide to PCB assembly inspection and testing options, testing procedures, and inspection measures to maintain product quality and reliability in the PCB manufacturing process.
